- Description
-
The Rako RMT500 wireless in-line RF dimmer is designed for GU10 LED lamps, tungsten, low-voltage halogen and other trailing edge dimmable loads.
A compact 500W RF dimmer designed to fit through a standard down-light cut-out of up to 50mm, the Rako RMT500 uses Trailing edge dimming technology for smooth quiet dimming of electronic transformer fed loads and maximises dimming performance of most GU10 LED down-lights. The dimmer is connected in-line before the first lighting fitting to enable dimming of up to 500W of trailing edge dimmable loads.
The unit can also be used for exterior lighting control applications, with the use of a weatherproof IP rated enclosure. The RMT500 is also the recommended dimmer for GU10 tungsten lamps due to its in-built short-circuit protection, necessary with this style of lamps. 16 Scene memory capacity, can be fully integrated into Rako wired systems. Easy set-up and manual On/Off control using the set-up button. Full rising clamp terminals and mounting bracket for easy installation. NOTE – THE RMT500 IS NOT SUITABLE FOR USE WITH INDUCTIVE OR WIRE-WOUND LOADS. Programmed using either an RCM/RCP RF wall-plate or RASOFT PC software suite, the RMT500 stores the House, Room and Channel address plus 16 preset scene levels in a non-volatile memory. The RMT500 dimmer can be controlled from any Rako transmitter such as RCM/RCP wallplates, RAH hand-helds and Bridge modules and forms the foundation of any Rako wireless scene-set system.
For install enquiries contact us on:
[email protected]
01189 882294
or on our website Live Chat
- Specification
-
Input supply: 230V AC +/-10% 50Hz
Weight: 120g
Ceiling mount cutout: 50mm or larger
Housing: UL V0 material
Climate Range:
Temperature +2C to +40C
Humidity +5% to 95% non condensing
Connections: 3 way screw terminals for mains power
Protection:
Auto resetting over current protection
Auto thermal shutdown
Voltage surge protection
Load types:
Mains Dimmable LEDs
Incandescent mains voltage lamps
Tungsten halogen GU10 lamps
Trailing edge dimmable LV
Transformers
Trailing edge dimmable cold cathode
Minimum Load: 1W
Maximum Load: 500VA refer to Rako when dimming GU10 style LEDs
Terminal Sizes: 4mm2
Standards:
Emissions - EN61000-6-3 : 2001
Immunity - EN61000-6-1 : 2001
Communication: Rakom coded fm radio, 433.9MHz
Memory: Flash memory (non volatile)
- Dimensions
-
Product dimensions: W.46mm x D.138mm x H.40mm
- Downloads
-
- Delivery and warranty
-
Delivery usually in 1-2 weeks
Supplied with a 3 year 'return to base' warranty
- About the manufacturer
-
Made in Britain, Rako smart lighting controls and systems are easy to use, easy to install & cost effective. Leading the way in providing state-of-the-art digital dimming technology, Rako provides innovative solutions for both wired systems (perfect for new build projects), wireless systems (ideal when it isn't possible to replace wiring) or a hybrid of both.
Perfect for modern living, Rako systems can be easily controlled with tablets, smartphones and smartwatches. Set up lighting scenes that allow you to select a pre-set lighting scene or change the mood lighting at the touch of a button. Rako offer a full suite of control panels, cover plates, control modules and dimmers, hubs and interfaces. If you're looking for fully integrated smart home mood lighting systems, you're in the right place.
Rako won the Smart Building Awards for Best Lighting Control product and the CEDIA EMEA Award for Best New Hardware for 2022.
