L-Tech 20W 250-1000mA CC Zigbee Tunable White LED Driver

Description

Use Zigbee protocol and Tuya application with high networking capability.
T-PWM™ dimming technology allows continuous and flicker-free images under high-speed photography.
With soft-on and fade-in dimming function, enhancing your visual comfort

Specification

Dimming interface: Zigbee Wireless Dimming
Dimming range: 0-100%, LED Startup Current<0.1%
DC Voltage Range: 120-300Vdc
AC Voltage Range: 100-240Vac
Output voltage: Max. 59Vdc
Output current: 250-1000mA
Output power: Max. 20W
Working temperature: ta: -20 ~ 50°C tc: 75°C

Dimensions

Product dimensions: W.167mm x D.32mm x H.41mm

Downloads

• L Tech SE 20 250 1000 W2Z2 Data Sheet

Delivery and warranty

In Stock - UK Next Day Delivery

About the manufacturer

With over 20 years experience in designing LED lighting control, L-Tech are experts in creating technologically state-of-the-art LED drivers. Transform your home into a smart home with intelligent lighting control.
