- Description
-
The smallest variation of the collection, Gea Frame XXS is a discreet yet powerful downlight producing approximately 100lm. Suitable for use in contemporary homes to pick out spots of interest such as furniture or pictures. With a baffle design, the recessed fixtures’ light source is hidden to prevent glare. Choose between a narrow 18°, medium 35° or wide 57° beam angle.
Crafted from an anticorodal aluminium body and heatsink, and a PMMA lens or opal PMMA diffuser. With energy-efficient LED technology integrated, Gea is available in 2200K, 2700K, 3000K, 4000K, red, green, or blue colour temperatures. Finishes in TXT White, TXT Black, and TXT Grey.
Spring not included for installation into plasterboard or wood. Installation into brickwork requires housing box (not included).
Series wiring – constant current driver required.
- Specification
-
IP40
Anticorodal aluminium body
Anticorodal aluminium heatsink
PMMA lens or opal PMMA diffuser
Cable: 25cm, 5m, 10m
C.C.
1 - 1,6W
1W - 350mA not included
1,6W - 500mA not included
1W 68lm 35°
1,6W - 101lm 35°
Wired in series
2200K / 2700K / 3000K / 4000K / RED / GREEN / BLUE
CRI 80 (2200K)
CRI 90 (2700K, 3000K, 4000K)
Optics:
18°, 35°, 57°
Installation:
Recessed on plasterboard or wood with spring (not included)
Recessed on brickwork through o-ring (included) and housing box (not included)
Accessories:
Torsion spring (ML021): Ø17,5 x 47 x 26
PVC Housing box (CAS20): Ø20 x 80 x Ø23
Lamp type: Integral LED: 1-1,6W
- Dimensions
-
Product dimensions: H.28mm x Diameter.24mm
Cutout dimensions: Dia.21mm
- Delivery and warranty
-
Delivery usually within 2-3 weeks
Supplied with a 2 year warranty covering manufacturing and/or design defects. The warranty does not cover:
- damage caused by transport
- the use of products in unsuitable environmental conditions
- non-standard product use or stress including under/over voltage
- damage caused by negligence or lack of maintenance
- damage caused by the use of power supplies not provided or indicated by LLD Light
- repair attempts or tampering performed by unauthorised staff
